/ Products / CISCO / CS-KITPRO-K9

CS-KITPRO-K9

CISCO Refurbished

Manufacturer: CISCO
Condition: Refurbished
Lead Time: 3-4 days
Availability: Not In Stock
Price: US$2,285.00 Enquire

CISCO's CS-KITPRO-K9 is a comprehensive video conferencing solution that combines all necessary equipment for a seamless video conferencing experience. The package includes a Cisco SX20 Quick Set video system, a Precision HD 1080p 12x camera, a touch 10 control panel, and a microphone kit. The SX20 Quick Set video system is designed for medium to large conference rooms and offers high-quality video and audio capabilities. The Precision HD 1080p 12x camera provides clear video and captures detailed images, while the touch 10 control panel simplifies video conferencing control. The microphone kit ensures high-quality audio and reduces background noise. With this kit, users can easily join video conferences and collaborate with remote teams with minimal technical knowledge. The kit is easy to set up and install, and the included equipment is integrated to ensure compatibility and optimal performance. The CS-KITPRO-K9 is ideal for businesses seeking a comprehensive video conferencing solution for their team meetings or client presentations.

Part Code: CS-KITPRO-K9
Description: Cisco Webex Room Kit Pro - Codec, Quad Cam, Touch 10 - GPL
Manufacturer: CISCO
End of Hardware Support: Yes
End of Sale: Yes
End of Life: Yes
Warranty

Feature summary

Expand

Product specifications

Expand

Product specifications

Specification

Software compatibility

Cisco Collaboration Endpoint (CE) Software Version 9.4 or later, or Cisco Webex Room OS

Default components in Room Kit Pro

Cisco Webex Codec Pro
Cisco Webex Quad Camera (a package is also available with the Precision 60 camera)
Cisco Touch 10 control unit
Wall mount for Quad Camera

Optional hardware components

Cisco Table Microphone (with Euroblock plug), wall mount for Codec Pro, rack mount for Codec Pro, various cables

Bandwidth

Up to 6 Mbps point-to-point

Minimum bandwidth for resolution/frame rate

720p30 from 768 kbps
720p60 from 1152 kbps
1080p30 from 1472 kbps
1080p60 from 2560 kbps

Firewall traversal

Cisco Expressway technology H.460.18, H.460.19 firewall traversal

Video standards

H.264, H.265, H.263 for TANDBERG MXP interop only (check Admin Guide)

Video inputs (6)

2 HDMI inputs support formats up to maximum 1080p60
3 HDMI inputs support formats up to maximum UHD (3840 x 2160) @ 30 fps including HD1080p60
One 3G-SDI/HD-SDI input supports formats up to maximum 1080p60
Extended Display Identification Data (EDID)
Consumer Electronics Control (CEC) 2.0

Video outputs (3)

2 HDMI outputs support formats up to 3840 x 2160@60 fps (4Kp60)
1 HDMI output supports formats up to 3840 x 2160@30 fps (4Kp30)
CEC 2.0

Encode and decode

Video stream: Full HD 1080p60
Content stream: 4K 2160p15

Audio standards

G.711, G.722, G.722.1, G.729AB, 64 kbps and 128 kbps MPEG4 AAC-LD mono and stereo, OPUS

Audio features

High quality 20-kHz audio
8 separate acoustic echo cancellers
8-port audio mixer
8 assignable equalizers
Automatic Gain Control (AGC)
Automatic noise reduction
Active lip synchronization

Audio inputs

8 microphones, 48V phantom powered, Euroblock connector, each with separate echo cancellers and noise reduction; all microphones can be set for balanced line level
3 HDMI, digital: stereo PC/DVD input

Audio outputs

6 balanced line level outputs, Euroblock connector
3 HDMI outputs
HDMI input #1 supports Audio Return Channel (ARC) audio output to Quad Camera
1 line out for subwoofer (Quad Camera)

Speakers (Quad Camera)

High-quality speakers
Frequency response 70 Hz to 20 kHz
Max output level SPL 90 dB

Speaker tracking (Quad Camera, SpeakerTrack 60)

6-element microphone array for accurate speaker tracking

Dual stream

H.239 (H.323) dual stream
BFCP Session Initiation Protocol (SIP) dual stream
Supports resolutions up to 3840 x 2160p15 fps and 1080p60

Wireless sharing

Cisco Webex clients (up to 3840 x 2160p5)
Cisco Intelligent Proximity client (up to 1920 x 1080p5)

Multipoint support

5-way embedded SIP/H.323 conferencing capability with MultiSite option

MultiSite features (embedded multipoint) (optional upgrade)

Adaptive SIP/H.323 MultiSite:
3-way resolution up to 1080p30 plus content up to 4Kp15
4-way resolution up to 720p30 plus content up to 4Kp15
5-way resolution up to 720p30 plus content up to 4Kp15
Full individual audio and video transcoding
H.323, SIP, and VoIP in the same conference
Support for presentation (H.239, BFCP) from any participant at resolutions up to 3840 x 2160p5
Best impression (automatic continuous presence layouts)
Encryption and dual stream from any site

Protocols

H.323
SIP
Cisco Webex

Embedded encryption

H.323 and SIP point-to-point
Standards-based: H.235 v3 and Advanced Encryption Standard (AES)
Automatic key generation and exchange

IP network features

DNS lookup for service configuration
Differentiated Services (DiffServ) (Quality of Service [QoS])
IP-adaptive bandwidth management (including flow control)
Automatic gatekeeper discovery
Dynamic playout and lip-sync buffering
H.245 dual-tone multifrequency (DTMF) tones in H.323
DTMF tones in SIP, RFC 4733
Date and time support using Network Time Protocol (NTP)
Packet loss-based down speeding
Uniform Resource Identifier (URI) dialing
TCP/IP
Dynamic Host Configuration Protocol (DHCP)
802.1X network authentication
802.1Q Virtual LAN
802.1p QoS and class of service
Cisco Media Assure and ClearPath

Call control

Cisco Collaboration Cloud / Webex
Cisco Unified Communications Manager (CUCM)
Native registration CUCM
Requires CUCM Version 10.5.2 or later with device pack for Room Kit Pro
Cisco TelePresence Video Communication Server (VCS)
Native registration with VCS
Third-party H.323 gatekeepers and standards-based SIP proxies

IPv6 network support

Single call stack support for both H323 and SIP
Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ
Support for static IP address assignment, stateless auto-configuration, and DHCP v6

Security features

Management using HTTPS and SSH
IP administration password
Password to access administration features on Touch controller
Disable IP services
Network settings protection

Certificate management

Certificate Authority Proxy Function (CAPF) support for additional security
Manufacturer-Installed Certificates (MIC)
Locally Significant Certificates (LSC)
X.509 Digital Certificates (DER encoded binary); both DER and Base-64 formats are acceptable for the client and server certificates; certificates with a key size of 1024, 2048, and 4096 are supported

Network interfaces Codec Pro

1 Ethernet (RJ-45) 10/100/1000 for LAN
2 Ethernet (RJ-45) 10/100/1000 for direct pairing with camera (camera control)
2 Ethernet (RJ-45) 10/100/1000 with PoE, 1 dedicated for direct pairing with Touch 10
Wi-Fi 802.11a/b/g/n/ac 2.4 GHz and 5 GHz for LAN
2x2 multiple input and multiple output (MIMO)

Other interfaces

2x USB A port, USB-B, uUSB, factory reset pinhole

Power supply (Quad Camera)

100 to 240 VAC, 50/60 Hz, 12V DC input
Standby 6W, average 20W, peak 70W

Operating temperature and humidity

0° to 40°C (32° to 104°F) ambient temperature
10% to 90% Relative Humidity (RH)

Storage and transport temperature

-20° to 60°C (-4° to 140°F) at RH 10% to 90% (noncondensing)

Dimensions

Quad Camera:
Width: 37.4 in. (95.0 cm)
Height: 4.7 in. (12.0 cm)
Depth: 4.0 in. (10.3 cm)
Weight: 10.6 lb (4.8 kg)
Codec Pro:
Width: 17.1 in. (43.6 cm)
Height: 2.6 in. (6.6 cm)
Depth: 9.1 in. (23.1 cm)
Weight: 7.3 lb (3.3 kg)
